Acoustic Leak Detection London
Our ground microphones and correlator equipment hear what you cannot. We locate leaks buried under concrete, behind walls, and underground without digging a single hole. Precision to within centimetres, even through thick slabs.
07456 975436Acoustic leak detection uses sensitive ground microphones and correlator technology to hear water escaping from pipes, even under concrete slabs and buried underground. Surveys in London cost between £150 and £300 and take one to three hours. No digging or damage required.
How Acoustic Leak Detection Works
When water escapes from a pressurised pipe through a crack, hole, or failed joint, it creates a distinct sound. This sound is generated by the turbulence of water forcing its way through the opening and vibrating the pipe wall and surrounding soil or screed. In most cases, this noise is far too quiet for the human ear to detect, especially when the pipe is buried underground or encased in concrete.
Our acoustic leak detection equipment changes that. We use electronic ground microphones that amplify these faint sounds by thousands of times, making even the smallest leak audible through our headsets. The equipment includes frequency filters that strip out background noise from traffic, appliances, and other sources, leaving only the characteristic sound of escaping water.
By moving the microphone across the surface systematically, our engineers listen for the point where the leak sound is loudest. This is the point directly above the leak. The process is methodical, accurate, and completely non-invasive. Combined with thermal imaging, we can confirm findings and give you absolute certainty about the leak location.
Correlator Technology for Precision Location
For buried mains supply pipes and long pipe runs where manual listening would be time-consuming, we use digital correlator technology. A correlator works by placing two sensors on the same pipe at known access points, such as stopcocks, valves, or inspection points. Both sensors pick up the leak sound simultaneously.
The correlator analyses the time difference between the sound arriving at each sensor. Because sound travels through the pipe at a known speed, the equipment calculates the exact distance from each sensor to the leak. This gives us a precise location, often accurate to within 10 centimetres, even on pipe runs buried several metres underground.
This technology is particularly valuable for mains water supply leaks under driveways, paths, and roads where excavation is expensive and disruptive. By pinpointing the leak before any ground is opened, we ensure that only a small, targeted excavation is needed for the repair.
When Acoustic Detection Is the Best Choice
Acoustic leak detection is the preferred method in several specific situations where other technologies have limitations. Understanding when acoustic is the right choice helps ensure you get the fastest, most accurate result.
Underground Mains Supply Pipes
The pipe from your water meter to the property is typically buried 600mm to 900mm deep. At this depth, thermal imaging cannot detect the temperature change at the surface. Acoustic equipment hears the leak directly through the ground, making it the only effective non-invasive method for these pipes.
Under Concrete Slabs
Many London properties, particularly flats and ground-floor extensions, have plumbing running beneath thick concrete floor slabs. Acoustic microphones pick up leak sounds through concrete with ease, and correlator technology can pinpoint the position along the pipe run without breaking the slab.
Pressurised Heating Systems
Central heating pipes running under floors often develop leaks at joints and bends. The pressurised water creates a strong acoustic signal that our equipment detects clearly. This is particularly useful for locating leaks in older London properties where pipe runs are not documented.
Commercial Properties
Large commercial buildings with extensive pipe networks benefit from acoustic detection because we can survey long pipe runs efficiently using correlator equipment. We regularly work on offices, retail units, and residential blocks across London.
Combining Acoustic with Other Methods
While acoustic detection is powerful on its own, we often achieve the best results by combining it with thermal imaging and tracer gas testing. Our thermal imaging service provides a visual confirmation of moisture patterns at the surface, while acoustic detection locates the pipe failure below. This dual approach is standard on our combined leak detection surveys.
For underfloor heating systems and central heating pipework, we typically start with thermal imaging to identify the area of concern, then use acoustic listening to confirm the exact pipe failure. This combination gives you certainty before any repair work begins.
The Equipment We Use
Ground Microphones
High-sensitivity electronic listening devices placed on the ground or floor surface. They amplify the sound of water escaping from pipes below, with adjustable frequency filters to isolate leak sounds from background noise.
Digital Correlators
Dual-sensor systems that calculate the precise leak position on a pipe by measuring the time difference between the leak sound arriving at two points. Accurate to within 10 centimetres on most pipe types.
Listening Sticks
Contact microphones placed directly on pipe fittings, valves, and stopcocks. These are used to trace the path of a pipe through a property and confirm whether a pipe section contains a leak before deploying more advanced equipment.
Acoustic Leak Detection Questions
What is acoustic leak detection and how does it work?
Can acoustic detection find leaks under concrete slabs?
When is acoustic detection better than thermal imaging?
How much does acoustic leak detection cost in London?
How long does an acoustic leak detection survey take?
Suspect an Underground Leak?
Our acoustic equipment finds leaks through concrete, soil, and stone. Call for a same-day survey across London.
07456 975436No Digging Required
Acoustic detection locates leaks through concrete, tarmac, and soil without any excavation. We only dig once we know exactly where the leak is, minimising disruption and reinstatement costs.
